Impact Pulverizer Manufacturers in Chennai

We are the dominant company in Chennai in the field of Impact Pulverizer Manufacturers. For any questions contact us.

Impact Pulverizer is one among the extensive range of Industrial Crushers that is designed for standard fine grinding of soft or semi-hard materials. It offers adaptability of operations and prevents blocking or development of deposits such as fatty or sticky substances. It offers a cool operation to preserve the color, flavor, and taste of the product. It is also used for other operations such as pulverizing, grinding, mixing, and dispersing with help of different grinding elements.

Features:

• Hammer and Liners are obtainable in many shapes and construction like MS, Hi MN Steel hardened alloy steel, stainless steel etc., to suit the material
• Primarily suitable and convenient range to pulverize the material up to 60 – 80 mesh
• Strongly constructed machine for crushing many spice, chemicals, Ayurveda Herbs, Agro Products
• Used without cyclone and dust collector for bigger output particle size and for fine material, a cyclone with dust collector is used
• Many type of material for liners and hammer as per consumer product for better result and best life of wear & tear

Operating principle of Impact Pulverizer / pulveriser

The impact pulverizer consists of an enclosed rotor carrying swing hammers, mixer classifier for excellence regulation and pressure gradient creator mounted on a solid shaft. Raw material to be pulverized enters the crushing chamber through the hopper or the automatic rotary feeder. The impact of the hammers on the feed material against the liner plates reduces it into fine powder. The ground material is carried towards the mixer classifier for classification and the immense particles are rejected by the classifier and returned to the crushing chamber for further grinding.

Construction of Impact Pulverizer (or) Pulveriser

Type: Air sweep impact mill with mixer classifier operation in closed circuit

Body: Solid iron machined and united on a strong iron base with top covers bolted.

Feeder: Automatic rotary feeder, gear ambitious from the main shaft with the feed control mechanism

Crushing Chamber: Lined with renewable solid iron breaker plates

Rotor: Machined mild steel thick plates mounted on main

Shaft: Solid alloy steel

Classifier: Mild steel Whizzer classifier with the adjustable spider to control the fineness of ground powder up to 300 meshes depending on the type of material being pulverized

Bearings: Self-aligning ball bearings in cast iron housing with suitable grease cups for lubrication Hammers: forged alloy steel, hard-faced, with manganese steel electrodes and balanced.

Visit us in Google Maps

FAQS

What is the use of pulverizer?

Pulverizers are used to pulverize pieces of coal into fine particles (100μm) before placing them into a boiler, to ensure efficient combustion. Pulverizers have three functions, pulverization, drying, and classification.

How many types of pulverizers are there?

Mainly there are three types of pulverizer used in industry: the slow speed mills like ball tube mills, the medium speed mills like bowl, ball, and race, roller mills fall in this type, and the third type is the high-speed impact mill.

Which type of pulverizer is used in medium crushing?

Rolling and rolling are mainly used for coarse and medium smashing. They are suitable for the crushing of hard materials and large blocks.
